Order Picker Platforms

Only %1 left

SKU

OPP

The Order Picker Platform (OPP) attaches to an order picker truck for upper-shelf picking to pallets or inventory replenishment directly from pallet loads. This durable steel platform is sized for the footprint of pallets or large bins.

Overview

Convert your order picker trucks to elevated platforms for selecting orders by attaching Order Picker Platforms (OPP) from BHS. These safe and dependable platforms provide access to top rows of shelving for order picking, pallet loading, stock putaway, inventory, and other elevated tasks.

Integrated fork pockets keep Order Picker Platforms securely attached to lift trucks. For even more flexible positioning, choose optional casters that allow the unit to be rolled into place. Two locking swivel casters and two rigid poly casters make the unit easy to maneuver for use or storage.

To purchase an Order Picker Platform, find your local BHS dealer by calling 1.800.BHS.9500.

Features & Benefits

Provides access to high shelving for order picking, pallet loading, stock putaway, or inventory
Designed to store standard pallets, providing high capacity storage
Heavy-duty steel construction with a durable powder-coat finish
Powder coated “BHS Yellow” for high visibility
Optional casters with wheel brakes improve maneuverability
Fork pockets designed for dependable attachment to forks
Custom designs available
Proudly designed and manufactured in the USA

Specifications

MODEL	PLATFORM W x D	OVERALL WIDTH	OVERALL DEPTH	OVERALL HEIGHT	CAPACITY	UNIT WEIGHT	FORK POCKET HEIGHT (A)*	FORK POCKET INSIDE WIDTH (B)*	FORK POCKET OUTSIDE WIDTH (C)*
OPP-4248	42” x 48” (1067 mm x 1219 mm)	45” (1143 mm)	48” (1219 mm)	50” (1260 mm)	1000 lb (454 kg)	400 lb (181 kg)	4” (102 mm)	2.6” (66 mm)	28” (711 mm)
OPP-4848	48” x 48” (1219 mm x 1219 mm)	51” (1295 mm)	48” (1219 mm)	50” (1260 mm)	1000 lb (454 kg)	421 lb (191 kg)	3.813” (97 mm)	16” (406 mm)	28” (711 mm)
OPP-4860	48” x 60” (1219 mm x 1524 mm)	51” (1295 mm)	60” (1524 mm)	50” (1260 mm)	1000 lb (454 kg)	500 lb (227 kg)	3.813” (97 mm)	16” (406 mm)	28” (711 mm)
OPP-4872	48” x 72” (1219 mm x 1829 mm)	51” (1295 mm)	72” (1829 mm)	50” (1268 mm)	1000 lb (454 kg)	580 lb (263 kg)	3” (76 mm)	17” (432 mm)	28” (711 mm)

MODEL

PLATFORM W x D

OVERALL WIDTH

OVERALL DEPTH

OVERALL HEIGHT

CAPACITY

UNIT WEIGHT

FORK POCKET HEIGHT (A)*

FORK POCKET INSIDE WIDTH (B)*

FORK POCKET OUTSIDE WIDTH (C)*

OPP-4248

42” x 48”

(1067 mm x 1219 mm)

45”

(1143 mm)

48”

(1219 mm)

50”

(1260 mm)

1000 lb

(454 kg)

400 lb

(181 kg)

4”

(102 mm)

2.6”

(66 mm)

28”

(711 mm)

OPP-4848

48” x 48”

(1219 mm x 1219 mm)

51”

(1295 mm)

48”

(1219 mm)

50”

(1260 mm)

1000 lb

(454 kg)

421 lb

(191 kg)

3.813”

(97 mm)

16”

(406 mm)

28”

(711 mm)

OPP-4860

48” x 60”

(1219 mm x 1524 mm)

51”

(1295 mm)

60”

(1524 mm)

50”

(1260 mm)

1000 lb

(454 kg)

500 lb

(227 kg)

3.813”

(97 mm)

16”

(406 mm)

28”

(711 mm)

OPP-4872

48” x 72”

(1219 mm x 1829 mm)

51”

(1295 mm)

72”

(1829 mm)

50”

(1268 mm)

1000 lb

(454 kg)

580 lb

(263 kg)

3”

(76 mm)

17”

(432 mm)

28”

(711 mm)

*Download PDF to reference diagram of fork pocket measurements

Options

Casters (OPP-C): 4” poly casters. (2) locking swivel and (2) rigid casters allow platform to be maneuvered by hand. Option must be specified at the time of order.
Anti-Skid Tape (SKIDTAPE): Textured tape on the platform deck adds traction.
