Modular Order Picker Platform

Overview

Configure Modular Order Picker Platforms to match your trucks, your tasks, and your evolving operational needs. This reliable steel base extends the working area of your operator platform. It also matches the truck platform’s height to eliminate tripping hazards.

Adjustable shelves allow you to set heights for parcels or pieces. Each shelf carries up to 300 pounds (136 kilograms). Lightweight construction allows you to devote more of your fork truck’s center capacity to materials. Open fork pockets ensure compatibility with most order picker trucks, while optional fork guides ensure a snug fit.

Modular Order Picker Platforms are built for extreme versatility. Optimize your Platforms with removable, bolt-on features. Choose handrails, operator guarding, adjustable fork guides, anti-skid tape, custom colors, and laser-cut brand logos.

Optional shelves feature laser-cut capacity markings, simplifying compliance and boosting safety. Maximize the productivity of your order picker fleet with Modular Order Picker Platforms from BHS, Inc. Call us at 1.800.BHS.9500 to learn more.

Looking for a material handling solution you can lift with an order picker or push across the floor via casters? Choose Modular Order Picker Carts from BHS, Inc.

Features & Benefits:

Expands working and storage areas for order picker trucks
Adjustable components provides versatile service
Bolt-on shelves for custom configuration in the field
Options include operator guarding, handrails, adjustable fork guides, and more
Custom platform heights prevent tripping hazards on order picker trucks
Open fork pockets for near-universal compatibility
Optional fork guides ensure tight fit for any lift truck
Light-weight, high-strength construction optimizes capacity for fork trucks
Shelf capacity of 300 lb (136 kg) each
Laser-cut capacities on optional shelves; optional laser-cut brand logos
Custom colors, dimensions, and capacities available on request
Proudly designed and manufactured in the USA

Specifications

MODEL	WIDTH	DEPTH	PLATFORM HEIGHT	PLATFORM CAPACITY	WEIGHT
OPPM-4042	40” (1016 mm)	42” (1067 mm)	4.7” (119 mm)	2,000 lb (907 kg)	85 lb (39 kg)
OPPM-4048		48” (1219 mm)			100 lb (45 kg)
OPPM-4060		60” (1524 mm)			130 lb (59 kg)
OPPM-4242	42” (1067 mm)	42” (1067 mm)			90 lb (41 kg)
OPPM-4248		48” (1219 mm)			105 lb (48 kg)
OPPM-4260		60” (1524 mm)			135 lb (61 kg)
OPPM-4842	48” (1219 mm)	42” (1067 mm)			105 lb (48 kg)
OPPM-4848		48” (1219 mm)			120 lb (54 kg)
OPPM-4860		60” (1524 mm)			140 lb (64 kg)
OPPM-6042	60” (1524 mm)	42” (1067 mm)			120 lb (54 kg)
OPPM-6048		48” (1219 mm)			135 lb (61 kg)
OPPM-6060		60” (1524 mm)			155 lb (70 kg)

Notes:

When ordering, identify the vertical offset between operator platform and top of fork. This allows the factory to size the platform to sit flush with the operator’s platform. See last page, diagram A. Overall Height will vary depending upon dimension supplied.
Overall dimensions may vary depending upon modular options.

Options

Fork Pockets (OPCMF-FP): Open fork pockets enable proper attachment of the platform to the order picker truck. Maximum outside of fork width is 30”. Consult factory to ensure correct size is ordered.
Adjustable Fork Guides (OPCMF-FP-GUIDE): Bolt-in, galvanized panels reduce outside fork pocket dimension to 27”, 25”, or 23” depending on installation position, creating a tighter fit within fork pocket compartment for any order picker truck.
Shelf Kit (OPCM-1TIER/2TIER/3TIER): Add one, two, or three shelves, available in 24”, 30”, 36”, or 42” depths. Each shelf features a 300 lb capacity, and adjusts in 3” height increments. OPCM can ship with shelves installed at desired heights if identified at time of order
Guarding (OPCM-GRD/GRDS): Slotted steel guarding helps keep the load contained, running the depth of the shelves and along the rear (GRDS). Guarding is also available for models without shelves (GRD) – identify depth at time of order (24”, 30”, 36”, or 42”).
Handrails (OPCMF-HR): Bolt-on steel handrails run entire depth and along back of deck. Includes kick plate and six safety harness attachment points. Adds 47.7” height to platform.
Anti-Skid Tape (SKIDTAPE): Textured tape on the platform deck adds traction.
Custom Lasered Logo (OPCMF-LOGO): Add a laser-cut logo plate to the rear of the platform to incorporate your company’s branding.
Custom Color: BHS Yellow is the standard powder-coat paint color for visibility in warehouses, however customers may choose from other colors. For more details, visit our Custom Colors webpage
